Product details

Rated voltage: AC100V～240V 50/60Hz

Input power: 300W

Light source specification: 19 15W four-in-one LED light source

Approved life: 30,000 hours

Color: red, green, blue and white, multiple colors

Focus: 8°-60° DMX linear adjustment Focus, with automatic focusing function.

Color temperature control: built-in CTO DMX linear dimming

electronic strobe: 0.3~25 times/second, synchronous or asynchronous random strobe

dimming: can be selected electronic dimming 0~100% linear adjustment, with gamma Horse-curve dimming frequency is adjustable from 1.2K to 25K, with macro dimming linear stability and smoothness without flickering. It adopts stable constant current drive and power supply, suitable for video shooting.

Rotation angle: XY axis is driven by high-speed silent motor, with high-precision imported The Hall positioning device makes the operation positioning more accurate. It can automatically return to the position after malfunction, and the horizontal and vertical speeds are adjustable; ° (16 bit precision scanning)

Control mode: 16 (simplified) 24 (standard); 2 channel control modes, standard DMX512 protocol, RDM protocol

control interface: DMX512 interface (3 core/optional 5 core), power cord hand in hand Socket

sleep function: Use advanced technology to realize remote sleep function. When the lamp disconnects the signal, it automatically enters the sleep state, making the lamp more stable and safer.

Display function: 1.77-inch LCD display, Chinese and English bilingual menu, sensor fault display, temperature display

Cooling system: Using high-conductivity light aluminum radiator, fan intelligent monitoring technology automatically adjusts the fan rotation speed according to the temperature of the lamp, built-in overheating protection intelligent system/intelligent temperature and noise balance module

Protection level: IP20, optional rain cover with protection level up to IP44

Lamp packaging: waterproof and shockproof flight case or carton

Net weight: 7KG

Gross weight: 8KG

Product size: 29*21*37CM

Packing size: 47*38*29.5CM (one in one)

Effect mode (Focus/beam) Lamp bead circle control effect: strobe, horse racing effect, with built-in program features:

1. Automatic screen rotation function, the system can automatically rotate the screen according to the direction of gravity, no manual rotation required! You can also turn off the automatic rotation function.

2. The integrated motherboard design solves the problems of smoke oil, colored paper, etc. It can individually control lamp beads, horse racing effects, built-in and other rich effects. The product has built-in RDM remote console dial-up upgrade function.
